Non Woven Fabric

Polypropylene spunbond needle punched geotextile

Polypropylene spunbond needle punched geotextile

Weight:100gsm-1000gsm
Material: 100% polypropylene
Width:1m~6m
Type: PP Geotextile
Description: The good-quality and cheap price Spunbond Polyester Nonwoven from Chinese factory.(Accept the OEM)
INQUIRY EMAIL

Polypropylene spunbond needle punched geotextile (PP Non woven geotextile for construction)is an important high-performance geosynthetics. This material plays an important role in the construction of irrigation works, hazardous waste landfill, tailings, the airport, high-speed railway and so on.

High-strength coarse-denier polypropylene spunbond needle-punched geotextile performance index

Project	TDF® < 100	TDF® < 150	TDF® < 200	TDF® < 300	TDF® < 400	TDF® < 500	TDF® < 600	TDF® < 700	TDF® < 800	TDF® < 1000
GSM(g/m2)	100	150	200	300	400	500	600	700	800	1000
Tensile Strength(kN/m)	6.5	10	16	21	30	37.5	45	50	56	65
Elongation(%)	40-110
CBR Bursting Strength (N)	1200	2000	2500	3800	5000	5600	7200	8700	9100	9400
apezoidal Tear (N)	180	460	650	750	1100	1200	1300	1450	1600	1750
Thickness(mm)	0.9	1.25	1.4	1.8	2.2	2.8	3.5	3.8	4.3	4.8
Grip Strength(N)	200	750	1000	1600	2000	2500	3500	4000	4350	4800
Holding Elongation(%)	50-120
Puncture Resistance(N)	190	330	420	550	800	920	100	1050	1300	1400
Fall cone penetration aperture(mm)	34	25.8	22.8	17.5	14	11.7	9.6	8.9	5.3	4.6
Equivalent aperture（O90）(mm)	0.26	0.21	0.16	0.11	0.08	0.08	0.08	0.07	0.07	0.06
Vertical Flow Rate I/m2/s	130	105	85	80	78	45	38	32	27	22
Vertical Permeability Coefficient	2×10-3
Chemical Resistance	No effect in the range of PH 2-13
UV Resistance	Strong retention rate >70%

·Light in weight. Density of polypropylene products is 0.91 g/cm3 (polyester is 1.38 g/cm3), so the polypropylene geotextile has a larger coverage area of the same quality geotextile under the same strength as the polyester geotextile.

·Good chemical stability. Polypropylene has excellent acid and alkali resistance, especially alkali resistance is superior to polyester. Polyester geotextiles are prone to irreversible hydrolysis under alkaline conditions or in the presence of large amounts of water, resulting in a loss or even complete loss of material properties, especially for areas that are in direct contact with alkaline interfaces such as cement, lime, and saline-alkali, while polypropylene Geotextiles are fully applicable to the above environment and do not pollute the environment.

·High mechanical properties. Polypropylene spunbonded needle-punched geotextile is made up of continuous polypropylene filaments. The tensile fracture form of the fabric is mainly the fiber breakage, while the staple fiber geotextile is mainly the extraction between the fibers. Therefore, strength,elongation and other mechanical properties of polypropylene spunbonded needle-punched geotextiles are better than staple fiber geotextile

·Good drainage performance. Polypropylene has excellent hydrophobicity, but has good water-conducting effect, and is superior to polyester in drainage engineering.

·The filtering effect is good. The polypropylene geotextile produced by our company can realize the compounding of different denier polypropylene non-woven fabrics, forming double-layer filtration and better filtering effect.

·Convenient construction. Polypropylene spunbond needle-punched geotextile has low needle density, soft and non-rigid cloth surface, and is more suitable for use. It is more convenient to lay and install.

In virtue of the superior physical properties and good chemical stability of PP geotextile, it can be applied to any geotechnical engineering environment，especially the environment with acid and alkali, such as highway, railway (HSR), airport, seaport, landfill, tailings dam, fly ash landfill, ash dam pool, artificial wetlands, rivers and lakes governance, reservoirs, canals, land reclamation, sewage treatment works etc.
